Installing an internal DAT tape drive20
Attach power cable
NOTE: The drive is not powered from the USB bus. It must be connected to the server's power
supply.
1. Attach a spare power cable from the server's internal power supply to the power connector.
Figure 10 Attaching power cable
1 and 5 USB cable, to server’s external USB port
2 and 4 power cable
3tape drive
6 server’s power supply
3
4
5
6
1
2
