Pairsplit-r operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of log information (0000000000 to 4294967295)
Detailed Information
Detailed information displays for this operation, as shown in Table 64.
Table 64 Pairsplit-r Operation
DescriptionItem
The port number, host group number, and LUN of the primary data volumeP-VOL (Port-G-ID-LUN)
The port number, host group number, and LUN of the secondary data volumeS-VOL (Port-G-ID-LUN)
The mirror IDMirrorID
The serial number of the logical device (storage system)S/N
The controller IDCTRLID
Indicates whether the split data volume is a primary or secondary data volume
P-VOL: Primary, S-VOL: Secondary
Type
Indicates whether writing to the secondary volume is enabled
Disable: Disabled, Enable: Enabled
S-VOL Write
The split range
LU: LU range, Group: Group range
Range
The suspend mode. Purge: Purge mode, Flush: Flush modeSuspend Mode
The result of operation
Normal end: Normal end, Error(xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
Result
The number of pairsNum. of Pairs
Pairsplit-S Operation
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,[Cnt Ac-J],Pairsplit-S,,Normal end,,,Seq.=xxxxxx
+{P-VOL(Port-G-ID-LUN),S-VOL(Port-G-ID-LUN),MirrorID,S/N,CTRLID,Type,Range,
Delete Mode,Result}=[{1A-0x00-0x000,5A-0x00-0x000,0x00,65432,5,P-VOL,LU,Normal,
Normal end},(snip)
-{1A-0x00-0x002,5A-0x00-0x002,0x00,65432,5,P-VOL,LU,Normal,Normal end},Num. of Pairs=3
[Cnt Ac-J]
HP XP Continuous Access Journal Software function
Pairsplit-S Operation
