DescriptionItem
The identification character 2 of the mapped external volumeVolumeID2
The device name that the mapped external volume notifies to the hostDevice
The capacity of the mapped external volume indicated by blocksCapa(blocks)
The number of the external volume group and the reference number assigned to the
external volume of the mapped external volume. The number on the left of a dash (-) is
the external volume number and the number on the right of the dash (-) is the reference
number of the group.
ExGroup
The path group number of the mapped external volumePathGroup
The CLPR number of the mapped external volumeCLPR
The emulation type of the mapped external volumeEmulation
The cache mode of the mapped external volume
Enable: Enabled, Disable: Disabled
Cache
The inflow control set to the cache of the mapped external volume
Enable: Enabled, Disable: Disabled
Inflow
The result of the operation
Normal end: Normal end, Error(xxxx-yyyyy): Abnormal end
xxxx: Part code, yyyyy: Error code
Result
The port name of the external port of the local storage systemPort
The WWN of the Target port of the external storage systemWWN
The LUN of the external volumeLUN
The number of mapping path (Port-WWN-LUN) configuredNum. of Paths
The LDKC, CU, and LDEV numbers of the LDEVs in the mapped external volume. The
number on the left of the colon is an LDKC number, the number between the colons is a
CU number, and the number on the right of the colon is an LDEV number
LDKC:CU:LDEV
The capacity of LDEVs in the mapped external volumes indicated by blocksLDEVCapa(blocks)
The SSIDSSID
The number of LDEVs in the mapped external volumesNum. of LDEVs
The number of mapped external volumesNum. of Volumes
BlockPaths(FIBRE) Operation
This logged information indicates that the Disconnect-Paths operation was only requested, but not
finished .
