HP StorageWorks XP20000/XP24000 - Disk Array - Page 167

Detailed information displays for this operation, as shown in Table 126.
Table 126 Install Operation (Installing Additional Power Supply)
DescriptionItem
The installed additional cluster power supply.
Redundant Power
Supply
The number of additional cluster power supplies.
Num. of Redundant
Power Supplies
Example 6 (installing additional battery)
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,[Install],Install,,Normal end,,,Seq.=xxxxx
+Power Lost Mode=Destage Mode
+Battery=[BATTERY-UR00,BATTERY-UR01,BATTERY-UR02,BATTERY-UR03],Num. of Batteries=4
[Install]
Install function
Install
Install operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of log information (0000000000 to 4294967295)
Detailed Information
Detailed information displays for this operation, as shown in Table 127.
Table 127 Install Operation (Installing Additional Battery)
DescriptionItem
The operation when power supply is lost.
Memory Backup Mode: Set to Memory Backup Mode
Destage Mode: Set to Destage Mode
Power Lost Mode
The mounting location of the batteryBattery
The number of batteries.Num. of Batteries
Install CV Operation
This logged information indicates that the formatting was only requested, but not finished. If the
operation does not require the formatting, this logged information indicates that the volume was
created.
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,[Install],Install CV,,Normal end,,,Seq.=xxxxx
+{PG,LDKC:CU:LDEV,Slot,Emulation,Size,Unit,System Disk,SSID}=[{1-1-(1),
XP24000/XP20000 Audit Log User and Reference Guide 167
