32 Remote Control Unit (RCU) Function
Add Path Operation
Example 1 (CU Free is used)
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,[RCU],Add Path,,Normal end,,,Seq.=xxxxx
+{S/N,MCU LDKC,RCU LDKC,Path Gr.ID,Controller ID}={99999,0x00,0x00,Default,4}
++{MCU Port,RCU Port}=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},{5G,7G},{1H,3H},{5H,7H}],
Num of Port Pairs=8
Example 2 (CU Free is not used)
user-name,xx,YYYY/MM/DD,HH:MM:SS.xxx, 00:00,[RCU],Add Path,,Normal end,,,Seq.=xxxxx
+{S/N,MCU LDKC,MCU,RCU LDKC,RCU,SSID,Controller ID}={99999,0x00,0x3F,0x00,0x7F,0x0004,4}
++{MCU Port,RCU Port}=[{1E,3E},{5E,7E},{1F,3F},{5F,7F},{1G,3G},{5G,7G},{1H,3H},{5H,7H}],
Num of Port Pairs=8
[RCU]
Remote Control Unit function
Add Path
Add Path operation
Normal end
The operation has ended normally.
Seq.=xxxxxx
Sequence number of log information (0000000000 to 4294967295)
Detailed Information
Detailed information displays for this operation, as shown in Table 234.
Table 234 Add Path Operation
DescriptionItem
Indicates a serial number of the device.S/N
The LDKC number of the connected LDKC.MCU LDKC
The LDKC number of the paired LDKC.RCU LDKC
The path group ID. When the path group ID is default setting, Default is output.Path Gr.ID
The controller ID.Controller ID
The CU number of the connected CU.MCU
