b. Remove the two Phillips PM2.0×3.0 screws (2) that secure the to the display assembly.
NOTE: The screw covers may be dicult to remove. If you need to replace the covers, a Mylar
screw cover kit is included in all display spare part kits.
c. Lift the top of the rear cover upward (1), and then lift the cover from the display (2).
The display rear cover is available using spare part number 792759-001 for horizon blue models
and 792762-001 for orchid magenta models.
7. If it is necessary to replace the webcam/microphone module:
a. Disconnect the webcam/microphone module cable (1) from the module.
Component replacement procedures 57
