Battery
Description Spare part number
Battery, 3-cell, 37-WHr, 3.25-AHr, Li-ion (includes cable) 787521-005
Before removing the battery, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the keyboard/top cover (see Keyboard/top cover on page 28).
Remove the battery:
1. Remove the four Phillips PM1.9×3.3 screws (1) that secure the battery to the base enclosure.
2. Remove the battery (2).
Reverse this procedure to install the battery.
36 Chapter 5 Removal and replacement procedures
