3. Remove the WWAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WWAN antenna is not connected to the terminal on the WWAN module, a protective sleeve
should be installed on the antenna connector, as shown in the following illustration.
Reverse this procedure to install the WWAN module.
38 Chapter 5 Removal and replacement procedures
