b. Align the riser card with the socket on the system board and press the riser card firm into the
socket.
NOTE: The riser card can be installed in only one way. Match the notch on the card with
the tab on the socket.
c. If a PCIe card was installed, reinstall it. For instructions, see Installing a PCI-Express card
on page 20.
d. Rotate the fan assembly down, push the fan assembly latch (1) toward the front of the
computer, lower the assembly (2) until it stops, and then release the latch.
14. Replace and latch the access panel, and then reinstall the I/O panel.
15. Replace the computer stand.
30 Chapter 2 Hardware changes

HP t620 Specifications

General

L2 cache	1 MB
Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Motherboard chipset	-
Processor frequency	1.65 GHz
Storage media	SSD
Card reader integrated	No
Total storage capacity	32 GB
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	Windows Embedded 8 Standard
Operating system architecture	64-bit
Product color	Black
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Country of origin	China

Weight and Dimensions

Depth	40 mm
Width	220 mm
Height	240 mm
Weight	1360 g
