HP V206hz - Installing the Wall Mount Plate

Wall Mount pad
E72
Installing the Wall mount plate
After moving the product to face
downward, make sure to place it on a
soft cloth or a cushion to avoid surface
damage.
Separate the head and the stand with
the use of a screwdriver.
This monitor satisfies the specifications of the Wall mount plate or the
interchange device.
Install the Wall mount plate.
Wall mount plate(Separate purchase)
This is stand-type or wall mount type and is connectable with Wall mount plate.
Refer to the manufacturer’s instructions that come with the wall mount plate.
Hole spacing : 100 mm x 100 mm.
Security Slot
Connected to a locking cable that can be purchased separately at most computer stores.
NOTE
VESA compatible only with respect to screw
mounting interface dimensions and mounting
screw specifications.
Please use VESA standard as below.
* 784.8 mm and under (30.9 inch)
- Wall Mount Pad Thickness : 2.6 mm
- Screw : 4.0 mm x Pitch 0.7 mm x Length
10 mm
* 787.4 mm and above (31.0 inch)
- Please use VESA standard wall mount pad
and screws.
