HP X32 - Frame and Panel Removal; Power Board Replacement

17
Remove the
middle frame
Remove the
screws by the
screwdriver
panel
Power board
The power board part number is ADPCK1908FGB
Before removing the power board, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 13.
Remove the power board:
1) The HP X32 power board connector position is as follows:
