Disassemble LED and power set
1. Disassemble LED lens（pic1）
2. Remove the cable from LED end in turn（pic2）
3. Pull out the connector vertically and take out
the power housing（pic3、pic4）
4. Take out thermal sensor（pic5）
12(1/1)
pic2
pic3
pic4
pic1
Remove the right hook
and the take out power set
pic5
Half finger insert 1
2020/7/1
0.20
