HP Z2 Mini G5 - Disassemble CPU fan, GPU fan

Document No. : Ludao disassembly SOP station :
Operation Name : Ver. : Edit date
Step：
Standard Operation Procedure
Notice: Please inform production line leader or master if you found any abnormal..
Fixture list (Spec.) Qty
Symbol
Safe
Order
Hear
Look
manu
al
Static
Qual
ity
Fix
tur
e
Issue Department：
Lister：
Zhou. Gui-lin
Industrial Engineering Class
Disassemble CPU fan、GPU fan
4(1/1)
1. Lift the fan（pic1）
2. Take the fan connector.（pic2）
3. Take the fan（pic3）
Tap the fan hook on either side
pic1
pic2
pic3
Half finger insert 1
2020/7/1
0.20
