HP Z220 SFF User Manual

Setting up SUSE Linux Enterprise Desktop (SLED)
HP offers a 64-bit SLED 11 preload on some Z series Workstations and supports 64-bit SLED 11 on
other workstations.
Various versions of SLED are certified and supported by SUSE on HP workstations. For more
information, refer to the SUSE certification bulletin search page at
http://developer.novell.com/
yessearch.
Setting up preloaded SLED
To set up SLED on systems preloaded with the operating system:
1. Start the workstation.
2. When prompted, enter the workstation installation settings: password, network, graphics, time,
keyboard settings, and SUSE Customer Center Configuration.
NOTE: You can activate your SUSE subscription from the SUSE Customer Center Configuration
screen. To view the full SUSE Customer Center documentation, go to
http://www.suse.com/
documentation and select your operating system.
Installing SLED with the CD Installer Kit
1. If an HP driver CD did not come with your workstation, create one (see HP Installer Kit for Linux
(HPIKL) on page 34.
2. Install the operating system using the CDs or DVDs included in the SUSE box-set.
3. After successfully installing the operating system, reboot the workstation.
4. Insert your HP driver CD. The HPIKL installation software automatically starts. Follow the prompts to
install the contents.
Warranty
HP provides configuration and installation support for SLED 11 on Z series Workstations for up to 90
days from date of purchase. SUSE also provides support for all versions of SLED that are certified on HP
workstations.
36 Chapter 5 Setting up and restoring Linux

HP Z220 SFF Specifications

General

Bus type	DMI
Stepping	E1
FSB Parity	No
Processor cache	8 MB
Processor cores	4
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v2
Processor socket	LGA 1155 (Socket H2)
Processor codename	Ivy Bridge
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16+1x4, 1x8+3x4, 2x8+1x4
Thermal Design Power (TDP)	77 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	32
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HDA
Product type	Workstation
Motherboard chipset	Intel® C216
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD-RW
Graphics card	Quadro 600
Power supply type	AC
Power requirements	100 - 240V, 50/60Hz
Networking features	Gigabit Ethernet (10/100/1000)
Graphics card family	Intel, NVIDIA
Maximum storage capacity	4 TB
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Number of displays supported (on-board graphics)	3
PS/2 ports quantity	2
USB 2.0 ports quantity	6
Parallel ports quantity	-
Chassis type	SFF
Product color	Black
Country of origin	China
Operating system installed	Windows 7 Professional
Power supply	240 W
Processor ARK ID	65733
Intel TSX-NI version	0.00
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	381 mm
Width	100 mm
Height	338 mm
Weight	- g
