A Technical Specifications
NOTE: All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Z22i Model
Display
Type
54.61 cm wide screen
IPS LCD
21.5 inches wide screen
Viewable Image Size 54.61 cm diagonal 21.5-inch diagonal
Maximum Weight (Unpacked) 5.7 kg 12.54 lbs
Dimensions (include base)
Height (highest position)
Height (lowest position)
Depth
Width
46.00 cm
33.37 cm
23.7 cm
50.9 cm
18.12 inches
13.13 inches
9.34 inches
20.05 inches
Maximum Graphic Resolution 1920 x 1080 (60 Hz) analog input
1920 x 1080 (60 Hz) digital input
Optimum Graphic Resolution 1920 x 1080 (60 Hz) analog input
1920 x 1080 (60 Hz) digital input
Environmental Requirements Temperature
Operating Temperature
Storage Temperature
5 to 35° C
-20 to 60° C
41 to 95° F
-4 to 140° F
Power Source 90 – 265 VAC at 45 - 63 Hz
Input Terminal One VGA connector; one DVI connector;
one DisplayPort connector (cable
inclusion varies by region)
NOTE: For the latest specifications or additional specifications on this product, go to
http://www.hp.com/go/productbulletin
and search for your specific display model to find the model-specific QuickSpecs.
Z23i Model
Display
Type
58.42 cm wide screen
IPS LCD
23 inches wide screen
Viewable Image Size 58.42 cm diagonal 23–inch diagonal
Maximum Weight (Unpacked) 6.2 kg 13.64 lbs
Z22i Model 19

HP Z23i Specifications

General

3D	No
Pixel pitch	0.252 x 0.252 mm
Aspect ratio	16:9
Response time	8 ms
Display surface	Matt
Display diagonal	23 \
Separate H/V sync	Yes
Display technology	LED
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 94 kHz
Supported video modes	1080p
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Mean time between failures (MTBF)	30000 h
USB hub version	2.0
DVI-I ports quantity	0
USB Type-A downstream ports quantity	3
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 30 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	36 W
Power consumption (standby)	0.5 W
Power consumption (typical)	28 W
Power consumption (PowerSave)	22 W
Certification	CB, CE, CEL Grade 1, TUV, GS, TCO, GOST, CUL, FCC, E-Star 5.0, CSA, NOM, S-Mark, VCCI, MIC, PSB, ISC, CCC, BSMI, C-Tick, ICES, Microsoft WHQL, TCO
Product color	Black
Country of origin	China
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Package depth	183 mm
Package width	620 mm
Package height	518 mm
Package weight	8400 g
Cables included	DVI, DisplayPort, USB
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	242.9 mm
Height (with stand)	469.9 mm
Weight (with stand)	6400 g
Depth (without stand)	51 mm
Width (without stand)	544 mm
Height (without stand)	329 mm
Weight (without stand)	4190 g
