1 Locating HP resources
This section provides information on the following resources for your HP workstation:
●
Product information
●
Product support
●
Product documentation
●
Product diagnostics
●
Product updates
Product information
Topic Location
Technical specifications Go to http://www.hp.com/go/quickspecs. In the left pane, select your region and then
select Workstations.
Regulatory, safety, and
environmental notices
See the Regulatory, Safety and Environmental Notices for product regulatory information.
You can also refer to the regulatory label on the workstation chassis.
Accessories For complete and current information on supported accessories and components, go to
http://www.hp.com/go/workstations.
System board A diagram of the system board is located on the inside of the chassis. Additional
information is located in the workstation Maintenance and Service Guide on the Web at
http://www.hp.com/support/workstation_manuals/.
Serial number and Certificate of
Authenticity (COA) (if applicable)
The serial number label is on the top or the side panel and also at the rear of the
workstation. The COA (Windows
®
7) is typically located near the serial number label.
Product information 1

HP Z240 Tower Specifications

General

Chipset	Intel C236
Memory Slots	4 DIMM slots
Processor Options	Intel Core i7, Intel Core i5, Intel Core i3, Intel Xeon E3-1200 v5, Intel Pentium, Intel Celeron
Memory	Up to 64 GB DDR4-2133
Storage Options	HDD, SSD, M.2 SSD
Graphics	Integrated Intel HD Graphics, NVIDIA Quadro, AMD FirePro
Expansion Slots	1 PCIe x16, 1 PCIe x4, 1 PCIe x1, 1 PCI
Front Ports	2 USB 3.0, 2 USB 2.0, 1 Headphone, 1 Microphone
Rear Ports	4 USB 3.0, 2 USB 2.0, 1 Audio Line-In, 1 Audio Line-Out, 1 Microphone, 1 RJ-45
Networking	Integrated Intel I219-LM PCIe GbE Controller
Power Supply	400W 92% efficient, wide-ranging, active PFC
Operating System	Windows 10 Pro, Windows 7 Professional, FreeDOS
