Swivel Range
45°L to 45°R
Height Adjustable
Yes, 0 to 120 mm
Pivot Rotation
Yes
Environmental
Temperature -
Operating
5° to 35° C
(41° to 95° F)
Temperature - Non-
operating
-20° to 60° C
(-4° to 140° F)
Humidity - Operating
20% to 80% non-condensing
Humidity - Non-
operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m
(16,404 ft)
Altitude - Non-
operating
0 to 12,192 m
(0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display
Glass
Yes
Low Halogen
4
Yes
Mercury-Free Display
Backlighting
Yes
Environmental Data
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
TCO 06
EPEAT® Gold where HP registers Commercial Display products. See
http://www.epeat.net
for registration status in your country US Federal
Energy Management Program (FEMP)
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
15.57 W 15.51 W
15.7 W
Sleep
0.16 W 0.22 W 0.15 W
Off
0.15 W
0.2 W
0.14 W
Heat Dissipation
*
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
53 BTU/hr 53 BTU/hr 53 BTU/hr
Sleep
1 BTU/hr 1 BTU/hr 1 BTU/hr
Off
1 BTU/hr 1 BTU/hr
0.4 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
QuickSpecs
HP Z24i 24-inch IPS Display
Technical Specifications
DA - 14672 Worldwide — Version 4 — October 3, 2013
Page 5
