HP Z27 User Manual

Method of LCM disassembly on LM270WR3-SSA1
Final : LED Array & C/Board & C/Bottom & LGP Holder

HP Z27 Specifications

General

3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	8 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.6 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1300:1
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 2560 x 1600 (WQXGA), 3840 x 2160
On/off switch	Yes
Pivot angle	0 - 90 °
Tilt angle range	-5 - 23 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
Product color	Black
Country of origin	China
Market positioning	Business
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	185 W
Annual energy consumption	62 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	70 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	510 mm
Weight (with stand)	9380 g
Depth (without stand)	54.5 mm
Width (without stand)	614.1 mm
Height (without stand)	365.4 mm
Weight (without stand)	6210 g
