HP Z32 User Manual

21
Table 4-2: Solving common problems
Problem
Possible cause
Solution
Screen is blank or
video is flashing.
Power cord is disconnected.
Connect the power cord.
Monitor is turned off.
Power the power button.
NOTE: If pressing the Power
button has no effect, press
and hold the power button
for 10 seconds to disable the
Power button lockout
feature.
Master power switch is set to off.
Set the master power switch
on the rear of the monitor to
the On position.
Video cable is improperly connected.
Connect the video cable
properly.
System is in Sleep mode.
Press any key on the
keyboard or move the
mouse to exit Sleep mode.
Video card is incompatible.
Open the OSD menu and
select the Input Control
menu. Set Auto-Switch Input
to Off and manually select
the input
Image appears
blurred,
indistinct, or too
dark.
Brightness is too low.
Open the OSD menu and
select Brightness to adjust
the brightness scale as
needed.
Check Video
Cable is displayed
on screen.
Monitor video cable is disconnected.
Connect the appropriate
video signal cable between
the computer and monitor.
Be sure that the computer
power is off while you
connect the video cable.
Input Signal Out
of Range is
displayed on
screen.
Video resolution and/or refresh rate are set higher
than what the monitor supports.
Change the settings to a
supported setting.
The monitor is
off, but it did not
seem to enter
into Sleep mode.
The monitor’s power saving control is disabled.
Open the OSD menu and
select Power Control >
Auto-Sleep Mode and set
auto-sleep to On.
On-Screen Menus
are Locked is
displayed.
The monitor’s OSD lock function is enabled.
Press and hold the Menu
button on the front bezel to
10 seconds to disable the
OSD lockout function.
Power Button is
Locked is
Displayed
The monitor’s power button is locked.
Press and hold the power
button for 10 seconds to
disable the power button
lock function.

HP Z32 Specifications

General

3D	No
Pixel pitch	0.18159 x 0.18159 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	31.5 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	29 - 60 Hz
Horizontal scan range	28 - 135 kHz
Viewable size, vertical	392.2344 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1300:1
Display number of colors	1.073 billion colors
Viewable size, horizontal	697.3056 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2520 x 1520, 2560 x 1440
On/off switch	Yes
LED indicators	Power
Tilt angle range	-5 - 20 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	185 W
Annual energy consumption	66 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	70 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black
Country of origin	China
Market positioning	Business

Weight and Dimensions

Depth (with stand)	248 mm
Width (with stand)	714.5 mm
Height (with stand)	564.4 mm
Weight (with stand)	12160 g
Depth (without stand)	44.5 mm
Height (without stand)	410.9 mm
Weight (without stand)	7590 g
