Front Panel Controls
Table 4-1 Monitor Front Panel Controls
Control Function
1 Menu Opens, selects or exits the OSD menu.
2 Minus If the OSD menu is on, press to navigate backward through
the OSD menu and decrease adjustment levels.
3 Plus/source If the OSD menu is on, press to navigate forward through the
OSD menu and increase adjustment levels.
If the OSD menu is inactive, press to activate the source
button that chooses the video signal input (VGA, DVI, or
DisplayPort)
4 OK/auto If the OSD menu is on, press to select the highlighted menu
item.
If the OSD menu is inactive, press to activate the auto
adjustment feature to optimize the screen image.
5 Power Turns the monitor on or off as long as the master power
switch on the rear panel is on.
6 Power LED Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
ENWW Front Panel Controls 19
