Workbench-mounting the router
Attach the rubber feet to the holes in the router bottom. Then place the router on
the workbench upside up.
3
4
Connecting a fiber port
Mount the router in the rack.
Installing an SD card
Remove the SD card slot cover, insert the SD card into the slot, and reinstall the
cover.
The device supports only JH318A SD cards. No JH318A SD cards are
provided with the device. Purchase a JH318A SD card as needed
.
Reinstall the cover after the installation.
!
1 2
Remove the dust plug from the fiber port, insert the transceiver module into the
fiber port, and connect the optical fibers to the port.
1 2
3
