5
6
Connecting an Ethernet cable
Connecting the grounding cable to the router
Correctly connecting the grounding cable is crucial to lightning protection and
EMI protection. Attach the ring terminal provided with the router to the
grounding cable. Make sure the grounding cable is reliably grounded.
!
1 2
Connecting the power adapter
Before connecting the power adapter, make sure the router is reliably
grounded.
To avoid bodily injury, first connect the power adapter to the router and then to
the equipment-room power supply system.
!
Supplying power to a device through PoE
Only the JH301A router supports PoE.
!
To supply power to a device through PoE, use an Ethernet cable to connect the
router to the device.
