Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD5L Series Controller User Manual －111－
Code Name Range Default Unit Attributes Setting
acc/dec)
D01.06 Output frequency 0.01－100.00Hz Actual value *
D01.07 Setting Rpm 0－24000rpm Actual value *
D01.08 Actual Rpm 0－24000rpm Actual value *
D01.09 Reserved *
D01.10 Output voltage 0－999V Actual value *
D01.11 Output current 0.1－999.9A Actual value *
D01.12 Output torque
0.0－300.0%(motor rated
torque)
Actual value *
D01.13 Output power 0－200%(motor rated power) Actual value *
D01.14 DC bus voltage 0－999V Actual value *
D01.15－D01.16 Reserved
Group D02 Analogue State Display Parameters (on pages 56
－
57)
D02.00 AI1 voltage 0.00－10.00V Actual value *
D02.01
AI1 voltage(After
disposal)
0.00－10.00V Actual value *
D02.02 AI2 voltage 0.00－10.00V Actual value *
D02.03
AI2 voltage(After
disposal)
0.00－10.00V Actual value *
D02.04 AI3 voltage 0.00－10.00V Actual value *
D02.05
AI3 voltage(After
disposal)
0.00－10.00V Actual value *
D02.06 AI4 voltage 0.00－10.00V Actual value *
D02.07
AI4 voltage(After
disposal)
0.00－10.00V Actual value *
D02.08 AO1 output 0.00－10.00V Actual value *
D02.09 AO2 output 0.00－10.00V Actual value *
Group D03 Running State Parameters (on pages 57
－
58)
D03.00 Heatsink temperature 0.0－999.9℃ Actual value *
D03.01 Input terminal state
Display in 16-bit binary, from
high to low bit is as follows:
Bit15－Bit12: Reserved
Bit11－Bit0 corresponds to
DI12－DI1
0: Connected
1: Unconnected
Actual value *
D03.02 Output terminal state
Display in 16-bit binary, from
high to low bit is as follows:
Bit15－Bit6: reserved
Bit5－Bit2 corresponds to
RLY4－RLY1
Bit1－Bit0 corresponds to
DO2－DO1
Actual value *
A
