Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―116― HD5L Series Controller User Manual
Code Name Range Default Unit Attributes Setting
F05.18
Over-speed detection
time
0.0－2.0s
0.0: No over-speed detection
0.2s 0.1s ×
F05.19
Detected value of speed
deviation
0.0－30.0%(F00.02) 20.0% 0.1% ×
F05.20
Detected time of speed
deviation
0.0－2.0s
0.0: no speed deviation
detection
1.0s 0.1s ×
F05.21 Reserved
F05.22 Creeping speed 0.000－0.400m/s 0.050m/s
0.001
m/s
○
F05.23－F05.25 Reserved
Group F06 Weighing Compensation Parameters (on pages 67
－
68)
F06.00 Pre-torque selection
0: No pre-torque
1: Analogue setting
2: DI setting
3: Digital pre-torque
4: No weighing
auto-compensation
4 1 ×
F06.01 Up pre-torque bias 0.0－100.0% 50.0% 0.1% ×
F06.02 Down pre-torque bias 0.0－100.0% 50.0% 0.1% ×
F06.03
Up electrical pre-torque
gain
0.000－9.000 1.000 0.001 ×
F06.04
Up brake pre-torque
gain
0.000－9.000 1.000 0.001 ×
F06.05
Down electrical
pre-torque gain
0.000－9.000 1.000 0.001 ×
F06.06
Down brake pre-torque
gain
0.000－9.000 1.000 0.001 ×
F06.07 Pre-torque digital setting -100.0－100.0% 10.0% 0.1% ×
F06.08 DI weighing signal 1 0.0－100.0% 10.0% 0.1% ×
F06.09 DI weighing signal 2 0.0－100.0% 30.0% 0.1% ×
F06.10 DI weighing signal 3 0.0－100.0% 70.0% 0.1% ×
F06.11 DI weighing signal 4 0.0－100.0% 90.0% 0.1% ×
F06.12－F06.13 Reserved
F06.14
No weighing current
coefficient
0－9999 3000 1 ×
F06.15
No weighing speed-loop
KP
1－9999 2000 1 ○
F06.16
No weighing speed-loop
KI
1－9999 2000 1 ○
F06.17－F06.20 Reserved
Group F07 Asynchronous Motor Parameters (on pages 68
－
71)
F07.00
Asynchronous motor
rated power
0.2－400.0kW
Depend on
controller
0.1kW ×
