Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD5L Series Controller User Manual －121－
Code Name Range Default Unit Attributes Setting
Hundreds: 0 normally open
input; 1 normally closed input
For example: set DI1 to 107,
the inspection input
disconnection is valid.
F12.13
MS in combination of
filter time
0.000－2.000s 0.010s 0.001s ×
F12.14 Reserved
F12.15 DO1 terminal function
0: Disable
1: Controller is ready
2: Controller is running
3: Controller is at zero-speed
running
4: Zero-speed
5: Contactor output control
6: Brake output control
7: FDT1
8: FDT2
9: Speed arrived signal (FAR)
10: Up signal output
11: Down signal output
12: Under-voltage
13: Reserved
14: Controller fault
15: Elevator stop
16－19: Reserved
2 1 ×
F12.16 DO2 terminal function 3 1 ×
F12.17 RLY1 relay function 14 1 ×
F12.18 RLY2 relay function 0 1 ×
F12.19 RLY3 relay function 0 1 ×
F12.20 RLY4 relay function 0 1 ×
F12.21
Output terminal logic
setting
Bit0,Bit1: DO1,DO2 output
terminal positive or negative
logic setting
Bit2－Bit5: RLY1－RLY4
relay output positive or
negative logic setting
0: Positive logic
1: Negative logic
00 1 ○
F12.22－F12.24 Reserved
Group F13 Analogue I/O Terminal Parameters (on pages 77
79)
F13.00 AI1 function 0: Disable
1: Speed setting
2: Weighing signal
3: Motor over-heating signal
input (only AI4)
0 1 ×
F13.01 AI2 function 0 1 ×
F13.02 AI3 function 0 1 ×
F13.03 AI4 function 0 1 ×
F13.04 AI1 bias -100.0－100.0% 0.0% 0.1% ○
F13.05 AI1 gain -10.00－10.00 1.00 0.01 ○
F13.06 AI1 filter time 0.01－10.00s 0.05s 0.01s ○
F13.07 AI2 bias -100.0－100.0% 0.0% 0.1% ○
