Shenzhen Hpmont Technology Co., Ltd Appendix B Communication Protocol
HD5L Series Controller User Manual －137－
7. Address Mapping
The controller’s function parameters, control parameters and state parameters are all mapped as
MODBUS’s read-write register. And their group numbers are mapped as the higher bytes of
register address while the relationships are shown as below table.
High bytes of register
address
Group number
High bytes of register
address
Group number
0x00 F00 0x01 F01
0x02 F02 0x03 F03
0x04 F04 0x05 F05
0x06 F06 0x07 F07
0x08 F08 0x09 F09
0x0a F10 0x0b F11
0x0c F12 0x0d F13
0x0e F14 0x0f F15
0x10 F16 0x11 F17
0x12 F18 0x13 F19
0x14 F20
0x32 Control parameter group 0x33 State parameter group
Their intergroup indexes are mapped as the lower bytes. Please refer to the instruction manual
for more details on function parameters F00
－
F20.
The users can realize the controller’s starting, stopping and running speed setting through the
control parameter, and obtain the controller’s running speed, output current, voltage etc. through
indexing the controller’s state parameters.
1. Control parameters
The controller’s control parameter intergroup indexes are as follows:
Register address Parameter name Retained or not at power loss
0x3200 Control command character No
0x3201 Main setting No
Definition of controller control command words:
Note:
The controller operating mode must be SCI control (F00.05 = 4).
B
