HQ HQ-PURE150-12 User Manual

3
General safety instructions
• Usethedeviceonlyasintended.
• Donotoperatethedeviceinadamporwetenvironment.
• Donotoperatethedeviceinareasthatarepotentiallyexplosive.
• Maintenanceandrepairworkmustonlybecarriedoutbyqualiedpersonnelwhoarefamiliarwith
the risks involved and the relevant regulations
Safety when installing the device
• Ensurethatthedevicehasarmfoundation.Thedevicemustbesetupandfastenedinsucha
way that it cannot tip over or fall down.
• Taketheprecautionsnecessarytoensurethatchildrencannotinterferewithoperation.Dangerous
situations may occur which cannot be recognized by children!
• Donotexposethedevicetoaheatsource(suchasdirectsunlightorheating).Avoidadditional
heating of the device in this way.
For installation on boats
• Ifelectricaldevicesareincorrectlyinstalledonboats,corrosiondamagemightoccur.Havethe
inverter installed by a specialist.
Electrical cables
• Ifcableshavetobefedthroughmetalwallsorotherwallswithsharpedges,useductsorwire
bushings to prevent damage to the cable.
• Donotlaycableswhicharelooseorbentnexttoelectricallyconductivematerial(metal).
• Donotpullonthecables.
• Donotlaythe230Vmainscableandthe12/24VDCcableinthesameduct.
• Fastenthecableswell.
• Laythecablessothattheycannotbetrippedoverordamaged.
• Operatethedeviceonlyifyouarecertainthatthehousingandthecablesareundamaged.
• Makesuretheairinletsandoutletsofthedevicearenotcovered.
• Ensureagoodventilation.
• Donotconnectthe230Voutputoftheinvertertoadifferent230Vsource.
• Evenafterthefusetriggers,partsoftheinverterremainlive.
• Alwaysdisconnectthepowersupplywhenworkingonthedevice.
Proper use
Thepuresinewaveinvertersconvert12Vor24Vdirectcurrenttoa230Valternatingcurrentata
frequencyof50Hz.
Warning!
Reverse polarity connection of the battery wires can damage the inverter. Do not use the inverter with
electrical systems using positive ground.
Withitslowweightandcompactdesigntheinvertercanbeeasilyinstalledintocampingmobiles,
commercial vehicles or motor and sailing yachts.
Theoutputvoltagecorrespondstothesocketstandard(puresinus-voltage)
Pleaseobservethevaluesforconstantoutputpowerandpeakoutputpower(foramaximumof10
minutes)asindicatedinthe“Technicaldata”section.
Neverconnectdevicesthathaveahigherpowerrequirement.
Note
Notewhenconnectingdeviceswithanelectricaldrive(suchaspowerdrillsandrefrigerators),thatthey
often need more power than is stated on the type plate.

HQ HQ-PURE150-12 Specifications

General

Purpose	Universal
Efficiency	85 %
Output power	150 W
Input voltage	12 V
Output current	0.65 A
Output voltage	230 V
Input frequency	- Hz
Output frequency	50 Hz
Power supply type	Auto
Power current type	DC-to-AC
Power protection features	Overheating, Overload
AC outlets quantity	1 AC outlet(s)
On/off switch	Yes
Product color	Blue
Package depth	245 mm
Package width	180 mm
Package height	110 mm
Package weight	1500 g

Weight and Dimensions

Depth	215 mm
Width	147 mm
Height	66 mm
Weight	1280 g
