HRESYS TL Series User Manual

TL-LFP Series LiFePO
4
Battery Operation Manual
discharging
maybe connection is abnormal.call
maintenance service for help.
If all temperature nearly the same,
check the environment temperature.
Low SOC alarm
Do not need to solve
Cell or system low voltage alarm
Do not need to solve
Environment temperature abnormal
Do not need to solve
Battery display
capacity different
from actual
capacity
SOC display deviation
Calibrate the SOC by fully charge and
discharge battery
Different flash status of LED indicators represents corresponding running status or alarms.
Detailed information is shown Annex 1.
Annex 1
–
Instructions for LED Flicker
Annex Table 1.1
–
SOC LED Indicators Description
●
●
●
●
SOC
☼
☼
☼
☼
75%~100%
☼
☼
☼
○
50%~75%
☼
☼
○
○
25%~50%
☼
○
○
○
0%~25%
Note: ☼ mean light on, ○ mean light off
Table 1.2 LED instructions:
Pack Status
Protect
/Alarm
/Normal
RUN
ALM
SOC LED
Description
●
●
●
●
●
●
Power down/Sleep
——
OFF
OFF
OFF
OFF
OFF
OFF
——
Standby
Normal
Flash 1
OFF
According to the SOC
Standby
Alarm
Flash 1
OFF
——
Charge
Normal
Flash 3
OFF
According to the SOC
——
temperature
Alarm
Flash 3
Flash
2
——
Overcharge
voltage
protection
Flash 1
OFF
Over
temperature,
Flash 1
Flash
2
