HRESYS TL Series User Manual

TL-LFP Series liFePO
4
Battery Operation Manual
4
1
Float voltage charge
V
54
2
Equal voltage charge
V
NA or 54
3
Standard charge current
A
0.2C
4
Charge current limitation
A
0.5C ~ 1.0C
5
LVLD (Low voltage load disconnection)
V
>44
6
LVBD (Low voltage battery disconnection)
V
>41
7
Temperature compensation for float charge
-mV/℃
NA
8
Temperature compensation for equalization
charge
-mV/℃
NA
NOTE: 1.Equalization charge is requested to switch off for TL-LFP series battery.
2.Rectifier parameter shall be set according to specific site requirement based on battery units used.
3.system instantaneous discharge and charge current shall be less than 250A for each module.
4.3 – Charge/Discharge Modes and Conditions
Table 4.3 Charge Modes and Conditions
Table 4.4 Discharge Modes and Conditions
Cell Temperature
Recommended Charge
Fast Continuous Charge
＜0
℃
No Charge Allowed
No Charge Allowed
0℃~ 10℃
Charge Current: 0.1C
Charge Current: 0.2C
10℃~20℃
Charge Current: 0.2C
Charge Current: 0.5C
20
℃
~30
℃
Charge Current: 0.3C
Charge Current: 1.0C
30℃~40℃
Charge Current: 0.3C
Charge Current: 1.0C
40℃~60℃
Charge Current: 0.3C
Charge Current:0.5C
＞60℃
No Charge Allowed
Cell Temperature
Recommended Discharge
Fast Discharge
＜-20℃
No Discharge Allowed
No Discharge Allowed
-20
℃
~0
℃
Discharge Current: 0.2C
Discharge Current: 0.5C
0℃~20℃
Discharge Current: 0.5C
Discharge Current: 1.0C
20
℃
~50
℃
Discharge Current: 0.5C
Discharge Current: 1.0C
50~60℃
Discharge Current: 0.2C
Discharge Current: 0.5C
＞60℃
No Disharge Allowed
