HS 311 - Parts Breakdown; Component Identification Diagram; Detailed Parts List

Parts Breakdown
Figure 6 Parts for Model 311
Figure No. Description Qty
1 Top Fitting* 1
2 Boom End Fitting 1
3 Bottom Fitting* 1
4 Boom Assembly 1
5
Rod Assembly (W/ Lock
Washers & Nuts)
1
6 End Stops 4
7 Bottom Fitting Hardware -
8
Boom End Fitting Hardware
-
*Mounting Hardware is supplied by others
*This figure is for reference only; actual crane may look different
19
1
3
5
2
8
6
4
7
