QUICKLAN 6055
EN - 3
2. GENERAL DESCRIPTION
The instrument allows the followed functions:
Wire mapping test on LAN cables with RJ45 connector
Test on UTP and STP cables
Up to 6 error conditions identified
Recognition of up to 8 remote units
Pass/Fail indications
Backlight
Auto Power OFF
3. PREPARATION FOR USE
3.1. INITIAL CHECKS
This instrument was checked both mechanically and electrically prior to shipment. All
possible cares and precautions were taken to let you receive the instrument in perfect
conditions. Notwithstanding we suggest you to check it rapidly (eventual damages may
have occurred during transport). Make sure that all standard accessories mentioned in §
7.4.1 are included. Should you have to return back the instrument for any reason please
follow the instructions mentioned in § 8.
3.2. POWER SUPPLY
The instrument is battery supplied with 1x9V alkaline battery type IEC 6F22 included in the
package. When the “ ” low battery indication symbol is displayed replace it immediately,
following the instructions given in § 6.2. Don’t replace the battery while the instrument is
connected to the plant.
3.3. STORAGE
After a period of storage in extreme environmental conditions exceeding the limits
mentioned in § 7.3 let the instrument return to normal measuring conditions before using it.
