HT GEO416 - Working Instructions; Instrument Description; Measuring Accessories Description

GEO416 - GEO416GS
EN - 5
4. WORKING INSTRUCTIONS
4.1. INSTRUMENT DESCRIPTION
CAPTION:
1. Inputs
2. ENTER/,,,keys
3. ESC/ key
4. RCL/CLR key
5. Display
6. GO key
7. SAVE key
8. ON/OFF key
Fig. 1: Instrument’s description
ENTER key to select measuring mode
Arrow keys to move the cursor selecting the required parameters
key to turn on the display backlight for 30 seconds
ESC key to quit without selecting any mode
RCL key to recall data stored in the instrument’s memory
CLR key to cancel the selected measurements from the instrument’s memory
GO key to start a measurement
SAVE key to store measurements
ON/OFF key to turn on/off the instrument
4.2. MEASURING ACCESSORIES DESCRIPTION
CAPTION:
1. Barrier
2. Hand-Held Area
Fig. 2: Measuring accessories description
