Page #19 background imageLoading...
Page #19 background image
HT60
EN - 16
6. TECHNICAL SPECIFICATIONS
6.1. TECHNICAL CHARACTERISTICS
Accuracy calculated as ±[%reading + (num. dgt*resol)] referred to 18°C28°C,<75%HR.
DC voltage (Autorange)
Range Resolution Accuracy Input impedance
Protection against
overcharge
4.000V 0.001V
(1.2%rdg + 2dgt)
7.8M
600VDC/ACrms
40.00V 0.01V
400.0V 0.1V
600V 1V
(1.5%rdg + 2dgt)
AC TRMS voltage (Autorange)
Range Resolution
Accuracy (*)
(50 400Hz)
Input impedance
Protection against
overcharge
4.000V 0.001V
(1.2%rdg + 8dgt)
7.8M
600VDC/ACrms
40.00V 0.01V
(1.5%rdg +3dgt)
400.0V 0.1V
600V 1V
(2.0%rdg + 4dgt)
(*) Accuracy specified from 5% to 100% of the measuring range, Frequency range: 50Hz 400Hz
Resistance (Autorange)
Range Resolution Accuracy Protection against overcharge
400.0 0.1 (1.2%rdg + 4dgt)
250VDC/ACrms
4.000k 0.001k (1.0%rdg + 2dgt)
40.00k 0.01k
(1.2%rdg + 2dgt)
400.0k 0.1k
4.000M 0.001M
40.00M 0.01M (2.0%rdg + 3dgt)
Diode test
Function Resolution Accuracy
Max voltage with
open circuit
Protection against
overcharge
1mV
(10%rdg + 5dgt)
approx. 1.5VDC 250VDC/ACrms
Continuity test with buzzer
Function Buzzer Test current
Protection against
overcharge
<30
<0.3mA 250VDC/ACrms
Frequency (Autorange)
Range Resolution Accuracy
Higher
Protection against
overcharge
5.000Hz 0.001Hz
(1.5%rdg + 5dgt)
>8Vrms 250VDC/ACrms
50.00Hz 0.01Hz
500.0Hz 0.1Hz
(1.2%rdg + 3dgt)
5.000kHz 1Hz
50.00kHz 10Hz
500.0kHz 100Hz
5.000MHz 1kHz
(1.5%rdg + 4dgt)
10.00MHz 10kHz
Note: in AC Voltage range, frequency range is: 10Hz 10kHz ; Sensitivity: > 15Vrms
