Usage
HTC 500
20 1.0
4.5.2. Changing grinding tools
1. Remove the grinding tool by giving it a few light taps
with a rubber hammer so the locking mechanism releases,
see Figure 4-5 on page 20. Then draw the tool up out of
the guide slot.
Figure 4-5 Removing grinding tools
2. Slide the grinding tool diagonally, from above, down into
the appropriate guide slot on the tool holder, see Figure
4-3 on page 19. Then push the tool fully into the guide
slot.
3. Lock the grinding tool into the tool holder by giving
it a few light taps with a rubber hammer - see Figure
4-4 on page 19.
4.6. Preparations for dry grinding
Warning!
Check that the splash guard is fitted.
1. Connect a dust extractor to the machine. For dust extractor
models, see under the Suction System tab in the HTC
Product Catalogue.
