8. Technical Data
The table below presents the technical data for the machine.
HTC 500 EU HTC 500 US HTC 500 US
Motor 4,0 kW 4,0 kW 4,0 kW
Current 10 A 16 A 22 A
Voltage 3 x 380-415 V 3 x 200-240 V 2 x 115 V
Total machine weight 180 kg 180 kg 180 kg
Chassis weight 78 kg 78 kg 78 kg
Weight, grinding head 102 kg 102 kg 102 kg
Weights 3 x 9,5 kg 3 x 9,5 kg 3 x 9,5 kg
Grinding diameter 530 mm 530 mm 530 mm
Grinding pressure with
weights
95-105-115-125 kg 95-105-115-125 kg 95-105-115-125 kg
Rotational speed 289 - 1301 r.p.m 289 - 1301 r.p.m 289 - 1301 r.p.m
Water tank 17 litres 17 litres 17 litres
Grinding discs 3 x 230 mm 3 x 230 mm 3 x 230 mm
Recommended minimum cable
area
2,5 mm² 2,5 mm² 6 mm²
Sound pressure level, average
value over time according
to ISO 3741, measurement
uncertainty according to class
1 measuring instruments for
sound level meters.
94 dBA 94 dBA 94 dBA
HTC 500 JP HTC 500 NO HTC 500 MS
Motor 4,0 kW 4,0 kW 4,0 kW
Current 16 A 16 A 9 A
Voltage 3 x 200 V 3 x 200-240 V 3 x 380-415 V
Total machine weight 180 kg 180 kg 184 kg
Chassis weight 78 kg 78 kg 82 kg
Weight, grinding head 102 kg 102 kg 102 kg
Weights 3 x 9,5 kg 3 x 9,5 kg 3 x 9,5 kg
Grinding diameter 530 mm 530 mm 530 mm
Grinding pressure with
weights
95-105-115-125 kg 95-105-115-125 kg 100-110-120-130 kg
Rotational speed 289 - 1301 r.p.m 289 - 1301 r.p.m 723 r.p.m
Water tank 17 litres 17 litres 17 litres
