HTC 500 - Page 43

HTC 500
Technical Data
1.0 35
HTC 500 JP HTC 500 NO HTC 500 MS
Grinding discs 3 x 230 mm 3 x 230 mm 3 x 230 mm
Recommended minimum
cable area
2,5 mm² 2,5 mm² 2,5 mm²
Sound pressure level,
average value over time
according to ISO 3741,
measurement uncertainty
according to class 1
measuring instruments for
sound level meters.
94 dBA 94 dBA 94 dBA
973
527
1074
1102
1494
1259
Figure 8-1 Height and length of the machine in millimetres
