Usage
HTC 650 HDX
18 1.0
Warning!
There is a risk of crush injuries when the weights are folded back,
since these are not locked in this position.
To obtain a greater grinding pressure, and thereby increased
grinding effect, the weights are lowered forwards, see Figure
4-3 on page 18.
Figure 4-3 Weights lowered forwards
During normal grinding, as well as during transport of the machine,
the weights should be placed in the up position, see Figure
4-4 on page 18.
Figure 4-4 Weights in the up position
During the exchange of tools and when tools with a high removal
rate (T-Rex™) are used, the weights should be folded back,
see Figure 4-5 on page 19.
