HTC GL 40 D - 7 Technical Data

HTC GL 40 D Technical data
2.0 33
7 Technical data
The tables and pictures below show the technical data and dimensions for the dust
extractor.
HTC GL 40 D
3x230V EU
HTC GL 40 D
3x400V EU
HTC GL 40 D
3x460V US
Part number 113110 113108 113109
Total machine weight 169 kg 169 kg 169 kg
Max. theoretical airflow 420 m³/h 420 m³/h 500 m³/h
Max. theoretical vacuum 260 mbar 260 mbar 260 mbar
Machine's initial airflow 375 m³/h 375 m³/h 470 m³/h
Machine's initial vacuum 20 mbar 20 mbar 20 mbar
Filter area, total, sock filter 0.975 m² 0.975 m² 0.975 m²
Filter area, Hepa 13 10.4 m² 10.4 m² 10.4 m²
Motor power 4 kW 4 kW 4.6 kW
Voltage 3 x 200-240 V 3 x 370-415 V 3 x 440-480 V
Current 15.5 A 9 A 9 A
Recommended minimum cable area 2.5 mm² 2.5 mm² 2.5 mm²
Frequency 50 Hz 50 Hz 60 Hz
Storage temperature -30...+50 ℃ -30...+50 ℃ -30...+50 ℃
Working temperature -5...+40 °C -5...+40 °C -5...+40 °C
Humidity 5-90 % 5-90 % 5-90 %
Sound power level, according to ISO 3741, measured
using class 1 instruments as sound level meters.
94 dBA 94 dBA 94 dBA
