HTC GL 40 D Introduction
2.0 3
• Dust extractor
• Manual disc
• Suction hose with couplings
• Locking key for control cabinet
1.6 Unpacking the dust extractor
Warning!
Read carefully through the safety instructions and user manual before using the
equipment.
• Check carefully to see if the packaging or the dust extractor has been damaged
during delivery. If there is any sign of damage, contact your retailer and report it.
• Check that the delivery matches the order. If there are any discrepancies, contact
your retailer.
1.7 Machine name plate
The dust extractor's model number is punched on the back of the motor's fixing plate.
The serial number is shown on the machine plate that is located in the electrical cabinet.
The machine name plate provides the following information. The model and serial
number must be specified when ordering spare parts for the machine.
Figure 1-1. Machine name plate
1. Model
2. Model number
3. Serial number
