HTP UFT-80W User Manual

11
LP-542 REV. 6.2.16
G. FREEZE PROTECTION FLUIDS
NEVER use automotive or standard glycol antifreeze, or ethylene glycol made for hydronic systems, with this boiler. Use only inhibited
propylene glycol solutions, which are specifically formulated for hydronic systems. Ethylene glycol is toxic and can attack gaskets and
seals used in hydronic systems.
Consider boiler piping and installation when determining boiler location.
NOTE: Damages resulting from incorrect installation or from use of products not approved by HTP, Inc. ARE NOT covered by warranty.
H. HIGH ELEVATION INSTALLATIONS
Natural gas at high elevation might contain less heating value than typical 1,000 BTU/cu ft and therefore can cause improper air / gas
mix leading to improper combustion. For natural gas installations above 3,000 ft, call your gas provider to determine the heating value
of the supplied natural gas.
PART 3 – TECHNICAL SPECIFICATIONS
MODEL
80W
100W
120W
140W
175W
199W
Installation
Indoor, Wall Hung, Fully Condensing
Minimum / Maximum Input (Btu/Hr)
8,000 /
80,000
10,000 /
100,000
12,000 /
120,000
14,000 /
140,000
19,900 /
175,000
19,900 /
199,000
Flue System
Sealed Combustion Direct Vent, Power Vent
Vent Run
2” (50 feet), 3” (100 feet), Schedule 40 PVC, CPVC, PP
Weight (lbs)
90
100
110
Gas Supply
Pressure
NG
3.5” to 14” WC
LP
3.5” to 14” WC
Power Supply
Main Supply
120V 60 Hz / 6a
Maximum Power
Consumption
160W
General Operating Conditions
Temperature
 Ambient Temperature Range: 33 – 104
o
F (0.6 – 40
o
C)
 Operating Relative Humidity: Up to 90% at 140
o
F (40
o
C)
 Shipping and Storage Temperature Range: -4 – 176
o
F (-20 – 80
o
C)
Input Ratings
Power Supply and Communication (CN4): 14V DC
Ignition System
Direct Electronic Ignition / Automatic Flame Sensing
Burner System
Premixed Fuel Modulation Ceramic Fiber Infrared
Gas Valve System
Combination Modulating (Current Proportional)
Internal Pipe Material
Copper
Dimensions
W 17.5” – H 34” – D 15.4”
W 19.7” – H 37” – D 16.8”
Boiler Heat Exchanger Capacity
3 Gallons
Main Controller / Control Panel
NGTB-900C / P-950EH
Water Pressure
Min 12 – Max 30 PSI
Connection
Sizes
Space Heating
Supply / Return
1 ¼” NPT
Gas Inlet
¾” NPT
Materials
Cabinet
Painted Cold Rolled Carbon Steel
Heat Exchanger
Heat Exchanger: Stainless Steel
Safety Devices
Optical Flame Sensor, Burner Plate High Limit (392
o
F), Water Temperature High Limit Sensor
(200
o
F), Gas Leak Detection Sensor (Detects Natural Gas or Propane), Freeze Protection
(Three Stage Operation - Activates at 46
o
F – See Freeze Protection in Installer Menu for
Details), Exhaust Temperature High Limit Sensor (190
o
F), Blocked Flue Switch, Condensate
Switch, Built-In Low Water Cut-Off Probe
Table 3 – Technical Specifications
