HTP UFTC-140 - Page 76

LP-648 Rev. 002 Rel. 002 Date 9.16.20
76
Figure 69 - Floor Model Replacement Parts
Item # Description 140 Model 199 Model Item # Description 140 Model 199 Model
1 Base Assembly, Floor Stand 7865P-001 7865P-002 10 Locknut - Electrical - 1/2” 7700P-002
2 Screw M5 x 12MM 7865P-023 11 Barb Fitting 1/2” 7100P-044
3 Anchor and Wall Bracket 7850P-084 12 Screw M4 x 10MM 7855P-390
4
Screw M6 x 12MM
(Not Shown)
7865P-024 13 3/4” ID SS Flex - 22” Long 7865P-017
5 Right Side Panel w/ Labels 7865P-010 7865P-011 14 3/4” ID SS Flex - 24” Long 7865P-018
6 Adapter, 1” x 1” 7865P-012 15 SS Gas Flex - 18” Long 7865P-015 7865P-016
7 Adapter, 3/4” x 3/4” 7865P-013 16 Condensate Hose 7855P-089
8 Adapter, 3/4” x 1/2” 7865P-019 17 Left Side Panel, Floor Stand 7865P-007 7865P-008
9 Adapter PVC, 3/4” x 1/2” 7450P-086 18 Front Cover Assy, Floor Stand 7865P-003 7865P-004
Table 46 - Floor Model Replacement Parts
