Figure 5-17 Connecting battery cables
----End
5.9 (Optional) Connecting Signal Cables
Context
When laying out signal cables, separate them from power cables and keep them
away from strong interference sources to prevent communication interruption.
Figure 5-18 Signal cable ports
SUN2000-(2KTL-6KTL)-L1
User Manual 5 Electrical Connection
Issue 10 (2023-02-13) Copyright © Huawei Technologies Co., Ltd. 58
