2 Hardware Structure
2.1 AP4050DN-E
Appearance
NOTE
The actual device appearance may slightly differ from the following device appearance, but these
differences will not affect device functions.
Figure 2-1 AP4050DN-E appearance
AP4050DN-E
Product Description
