l Different types of cables must be separately routed with the minimum spacing of 30 mm
and cannot be entangled or crossed. Cables should be parallel or separated using
dedicated separators.
l Bundled cables are closely arranged, straight, tidy, and undamaged.
l Cable ties are bound neatly facing the same direction, and those at the same horizontal
line must be in a straight line. Cable tie tails should be cut smoothly and evenly.
l Labels or nameplates must be attached to the cables after they are installed.
Connecting USB Flash Drivers
To ensure compatibility between USB flash drives and devices, use Huawei-certified USB
flash drives (listed in Table 2-4) to configure the Huawei devices.
Table 2-4 Huawei-certified USB flash drives
Capacity
Vendor Model Remarks
4 GB Netac U208 You can buy Netac USB 4 GB flash
drives from Huawei or other vendors.
SanDisk Cruzer Blade Huawei does not offer this USB flash
drive, and you need to buy it from other
vendors.
Hewlett-
Packard
v218G Huawei does not offer this USB flash
drive, and you need to buy it from other
vendors.
PNY M1 Huawei does not offer this USB flash
drive, and you need to buy it from other
vendors.
8 GB Netac U208 Huawei does not offer this USB flash
drive, and you need to buy it from other
vendors.
Hewlett-
Packard
v225w Huawei does not offer this USB flash
drive, and you need to buy it from other
vendors.
STEC SLUFD8GU2T
UI
Huawei does not offer this USB flash
drive, and you need to buy it from other
vendors.
Connecting the Ground Cable
Use ground screws and ground cables to ground the AP. The ground cables need to be
prepared on site. The M6 OT terminal is used to connect to the AP and M8 OT terminals to
the ground bar. The type of OT terminals can also be determined according to site surveys.
Cut the cable into the required length according to site conditions.
Tighten the OT terminal for the AP with a torque of 3 N•m. The tightening torque for the
ground bar varies according to the OT terminals used.
