Page #18 background image
Issue 05 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
AP8030DN
Product Description
2 Hardware Structure
Type
Color
Status
Description
Fault
Red
Steady on
A fault that affects
services has
occurred, such as a
DRAM detection
failure or system
software loading
failure. The fault
cannot be
automatically
rectified and must be
rectified manually.
Link/ACT indicators consist of Link/ACT0, Link/ACT1, and Link/ACT2, showing link status
of interfaces GE0/PoE, GE1, SFP respectively.
Table 2-2 Descriptions about the Link/ACT indicator
Type
Color
Status
Description
LINK
Green
Steady on
The system is running properly, the Ethernet
connection is normal, and no data is being
transmitted.
ACT
Green
Blinking
The system is running properly, the Ethernet
connection is normal, and the AP is transmitting
data. The indicator blinks more quickly when more
data is being transmitted.
Wireless indicators consist of Wireless0 and Wireless1, showing wireless link status of the
2.4/5 GHz and 5 GHz radio interfaces respectively.
Table 2-3 Description about the Wireless indicator (Traffic volume indicator)
Color
Status
Description
Green/yellow
Off
Radios are disabled, and no STA is
connected to the AP.
Green/yellow
Steady on
The AP has STAs connected to the 2.4 GHz
radio or 5 GHz radio, but no data is being
transmitted.
Green
Blinking
The AP has STAs connected to the 2.4 GHz
radio and is transmitting data. The indicator
blinks more quickly when more data is
being transmitted.
