Figure 4-12 Appearance of the shield layer
Figure 4-13 shows the appearance of the non-shielded cable.
Figure 4-13 Appearance of the non-shielded cable
RJ45 connectors are used at both ends of a network cable. Figure 4-14 shows an RJ45 connector
and Figure 4-15 shows the structure of the network cable.
Figure 4-14 RJ45 connector
PIN#1
PIN#8
