Huawei ATN 905 - Appearance of an IMB Network Cabinet; Internal Structure of an IMB Network Cabinet; Technical Specifications of the IMB Network Cabinet

Figure 4-20 Appearance of an IMB network cabinet
Figure 4-21 Internal structure of an IMB network cabinet
Table 4-35 lists the technical specifications of the IMB network cabinet.
Table 4-35 Technical specifications of the IMB network cabinet
Item
Specifications
Dimensions (H x W x D) 560 mm x 180 mm x 425 mm
Available installation space 3 U (1 U = 44.45 mm)
Temperature range -20°C to +50°C
