Huawei B310 User Manual

2
2 Setup
Insert a SIM card into the SIM card slot as shown in the preceding diagram and then
connect the power adapter to the B310 router. The router will turn on automatically and
search for available mobile networks.
The following indicators will turn on when the router has successfully connected to a
network.
Cyan/blue/yellow: Connected
to a mobile network.
White: More signal bars
indicate a stronger signal.
Do not insert or remove a SIM card when the router is running, as this may affect
performance or damage the SIM card.

Huawei B310 Specifications

General

Model	Huawei B310
Category	Network Router
4G LTE	Yes
Wi-Fi Standards	802.11b/g/n
Wi-Fi Speed	Up to 300 Mbps
Max Download Speed	150 Mbps
Max Upload Speed	50 Mbps
USB Port	No
SIM Card Slot	Yes
Max Wi-Fi Users	32
Battery	No
Weight	226 g
External Antenna	Yes
