9.7 WLAN Failure
Reference Figure 9-7
WLAN Failure
Check whether
WLAN antenna are normal？
Replace the
antenna
Check whether J4101&Z4101
are normal？
Replace the
faulty
components
Replace the U3101
Y
N
N
Replace U4102. Check
whether it is normal?
End
Y
Y
N
Measure whether output signal
value of the X4001 is normal?
Replace the
X4001
N
Replace U4001, check
whether it is normal?
End
Y
Y
N
Upgrade the software.
Then inspect if it is normal?
End
N
Y

Huawei E5331 Specifications

General

Wi-Fi	Yes
WLAN data transfer rates supported	21 Mbit/s
Data network	3G, EDGE, GPRS, HSDPA, HSPA+, HSUPA
GPRS multislot class	-
Device type	Cellular wireless network equipment
Product color	White
Compatible operating systems	Windows XP / Vista / Windows7 / Mac OS 10.5 / Mac OS 10.6 / Mac OS 10.7
Market positioning	Portable

Weight and Dimensions

Depth	60 mm
Width	92.8 mm
Height	12.8 mm
Weight	82 g
