Huawei NE05E Series

6
NE05E-SG/NE05E-SH/NE05E-SI/NE05E-SQ
Clock interface
Power supply interface
Time interface
NM interface
(Console interface)
Electrical interface
GE optical interface
Alarm interface
E1 interface
10
10
FE/GE optical
interface
FE/GE optical interface
FE/GE electrical interface
Power supply interface
Clock interface
10GE optical interface
Antistatic jack interface
Time interface
NM interface
(Console interface)
Alarm interface
For running an AC NE05E-SQ, you must turn on the switches of both AC power modules
operating in 1+1 backup mode.
NOTE
10
10
PGND point
PGND point
